Acid-Free Coconut Shell Activated Carbon

free Domestic shipping! USA Flag
International shipping is available - if your country is not listed, please contact us
Acid free coconut shell activated carbon by 4D Filtration

Activated Carbon


  • Low-dust coconut shell granules
  • Acid free (testing)
  • Vacuum-sealed & zipper to ensure purity
  • Nominal mesh size: 4 x 8
  • Manufactured in a NSF/ANSI certified plant
  • 300 g (10.58 oz) is six refills for P Mini and one refill for Promethean

Activated Carbon Specifications

  • Mesh Size: 4 x 8 (90% minimum), <5% greater than 4, <5% less than 8
  • Mesh 4 x 8 contains granules between 0.094-0.188 in ( 2.38-4.76 mm)
  • Iodine Number: 1,100 mg/g (minimum)
  • Ash Content: 5% (max)
  • Density: 28-33 lbs/ft3 (0.45-0.53 g/cc)
  • Promethean Refill: 300 g
  • P Mini Refill: 50 g

Applications For Activated Carbon

  • Industrial:3D Printing VOCS (FFF/SLA/etc), Soldering Fumes, CO2 Emissions
  • Personal:Cigarette & Marijuana Smoke, Household Fumes, Cleaning Chemicals, Atmospheric Dust, Forest Fire Smoke, Formaldehyde from new furniture, buildings, & paint
  • Non-Air:Water Purification, Spill Cleanup

Activated Carbon FAQ

Our carbon has less dust than other wood or coal-based carbon, but it will have slightly more dust than acid-washed coconut carbon.

Our coconut shell carbon is not acid-washed, as residual acid can corrode metal on your 3D printer.

Acid-washed coconut carbon ash content: <3-5%
Non-acid washed coconut carbon ash content: <5%
Coal-based carbon ash content: ~8-15%

This carbon is separated in an effort to provide flexibility on replacing filters, to reduce costs for gas purification applications, and to minimize waste through utilizing reusable cartridges.

The activated carbon should be replaced every 3 months. For higher-load applications the carbon should be replaced upon the reemergence of odors.

In large quantities spent carbon is typically reactivated as part of a recycling process, and it can be beneficial for yards (google biochar). However, since your spent carbon will contain toxins it is recommended to dispose of it. We may launch a recycling program in the future.

Volatile Organic Chemicals are gaseous compounds under standard atmosphere that are generally toxic in high concentrations.

We use coconut shell carbon instead of coal in order to minimize both the ash content and the environmental footprint.

It is recommended to keep humidity below 70% as excessive humidity can decrease the efficiency of activated carbon.
